OEM+ Short Shift Assembly - You chose the specs! Front to Back AND Relay lever

HOT H2O

Go Kart Champion
Location
Canada
As the title states - I am offering a unique opportunity for someone to get an OEM+ Short Shifter, modified to spec - $120+

What's included
* OEM Custom modified Front to Back (F2B)

I can also supply you with
* OEM Metal Relay or Side to Side lever
* OEM friction piece and pivot bushings for relay lever
* OEM lock washers/circlips




I have assembled and tested several 'kits', for both myself and for friends on both the 5 and 6MTs from MK4s to MK7s


This is a true OEM+ upgrade. The cast lever has a nice weight to it, in fact most everyone prefers the weight of the cast lever when shortened over an aftermarket billet aluminum lever.


I will also be replacing the pin, and relocating it closer to the pivot/fulcrum - YOU GET TO CHOOSE! I personally recommend somewhere between 45 and 55mm. For reference, all the aftermarket levers with two selectable holes have both a 50 and a 40mm setting. I can also do multiple positions to give you an adjustable lever


Based on your preferences for how short you wish to have your throw I will also be hand sculpting the cast lever, then sealing it.


You will get a selectable OEM+ Short Shift Lever based on your input/requirements


I can also provide the metal OEM Relay lever which not only is much more robust and precise vs the newer plastic OEM levers, but it also reduces your side to side movement by about 10% which is perfect in my opinion.




Here is an assembly I just made for a MK7 R




Here is the assembly I had in my MK6 R. (Please note I do not have the shift cable bracket available, nor are the 42DD bushings included - but I can advise you on which ones to get if you choose to go with solid shift bushings as well - I highly recommend the 42DD Bushings!)





I relocated the pin to 48mm from fulcrum in this example





Here's a look at what's involved

Stock MK7 R/GTI Lever





Removing original pin






Sculpting the metal to accommodate the end link and cable with a shorter throw






Checking my distance..





..and my level





Pilot hole carefully drilled





Perfect!






for comparison - OEM MK7 Lever originally 69mm pin to fulcrum






tapping hole for new pin






I've retained the ability to return new pin to original location if desired.





test fit of new pin - perfect! (not all the way down in this pic)






more sculpting





Adding a personal touch to my new lever :D (note - not finished, still have to do some finishing work and paint)


Last edited:

HOT H2O

Go Kart Champion
Location
Canada
Damn man

Sent from my XT1254 using Tapatalk


Here is a finished example of the Front to Back lever - gave it that 'Vintage' feel. I like how some of the finer file marks give it character.


I filled the etched script in with paint, then sanded.. then used a special clear coat for raw metal applications.



HOT H2O

Go Kart Champion
Location
Canada
Wow! That's great work. How hard would you say the installation is for someone who has no experience of working on cars?

It's fairly straightforward. I taught a friend who has never done it how to install them.

There are some great videos on how to adjust your shift linkage afterward - it's extremely straightforward and pretty much impossible to mess up if you follow instructions.

It sounds much more daunting than it actually is.


ITGUY

Drag Race Newbie
Location
PA
Wow this takes a lot of the guess work out on purchasing the parts.. I would be interested in this too


ITGUY

Drag Race Newbie
Location
PA
Just installed mine a few days ago and so far it's been great!!!!!!
